Electric Hood Type Dish Washer With Pre Cleaning And Exit Table

Basic Information
Place of Origin: Guangdong China
Brand Name: Willco
Certification: ce, CSA
Model Number: WL41329
Minimum Order Quantity: 2 pieces
Price: Negotiate
Packaging Details: Drawer Dish Washer packed with splints, carton, foam.
Delivery Time: 30 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Sets/ per momth
Detail Information
Product Name: Dish Washing Machine Power Source: Electric
App-Controlled: NO Place Of Origin: Guangdong, China
Control Type: Semi-Integrated Style: Traditional
Function: Strong Dish Washing Housing Material: Stainless Steel
Inner Material: Stainless Steel Type: Freestanding
Voltage (V): 220 Power (W): 9000
Keyword: Dish Washing Machine Water Consumption: 390L/hour
MOQ: 1piece
Highlight:

Electric Hood Type Dish Washer

,

Pre Cleaning Hood Type Dish Washer

,

commercial hood type dishwasher


Product Description



Electric Hood Type Dish Washer With Pre-Cleaning And Exit Table

dimension with wooden pakage
850*950*1550mm
voltage&Power
380V/9.8KW
dimension
730*830*1430mm
Gross Weight
130KG/PCS
washing capacity
60 frames/H
water consumption
2.8L/H
rinse temperature
80-90℃
main temperature
60-65℃
Inlet water pressure (kg/C㎡)
2-5kg/C㎡
Inlet size
G1/2"
drain size
θ50
washing basket inlet size
500*400mm
Place of Origin
China Guangdong
Brand Name
Willco
Model Number
WL41329
Product Parameter


















Product Description :



Total power::50KW/380V, national standard line 25 square copper core wire, 125A leakage switch, 1.6 meters above the ground to install the
leakage switch, reserve 4-5 meters of cable, and reserve 4 points of water inlet valve above the ground height of 40CM about.

The entrance is equipped with a drawer-type residue filtering device, and the filter screen can be easily taken out and cleaned during machine operation.
The side of the electrical panel is equipped with an emergency stop switch, allowing operators to quickly stop the machine in case of emergency.
The double-rinsing system ensures effective washing results.

 It can be configured with a high-efficiency pre-washing and drying system to achieve higher hygiene standards.
It is equipped with an overload protection device, which can promptly stop the operation in case of overload to prevent damage to the machine and tableware.





Features :





Turn on the water switch, check the water pipe, percolation net, then open the door of the machine.

Turn on the power and the power light will turn green.

Press down the watering button on the control table, temperature light will turn red, machine start working.

Dishwasher will start heating automatically after affusion finished.

Dishwasher will stop heating automatically once the temperature come up to the prearranged point.

All scour will be injected into the washing machine automatically after set up the distributor.

Do not put your hand into the washing bucket, put the cup and glass ware into the basket, all trays must be leaned onto the washing dishes and face up, silver dishes face down. Commercial Restaurant Kitchen Dishwasher Machine For Sale And Price





Advantages :



  • 316 Heating TubeLonger Service Life
  • High quality 304 stainless steel for whole machine
    Use high quality 304 stainless steel, which can make the whole machine moredurable,Wear-proof and increase of service life
  • Rotary spray arm
  • Easy to operate panel
    Intuitively operate panel,simply washing and easy to master,one-button easyoperation and conveniently fast.
  • Uncover Handle
  • One-stop thorough cleaning
    Washable different tableware, such as stainless steel, ceramic, glass.
    bowl, plate, chopsticks, knife, wine rack and so on.





Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 0





Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 1

Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 2




Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 3









Production Process


Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 4



Company Profile




Guangzhou Weike Trading Co., Ltd. is a senior enterprise integrating product research and development, production, sales and service. The company's trash cans, railing seats and other products are widely used in parks, streets, airports, bank lobbies, hotel lobbies and other places. , the products are sold at home and abroad, and are recognized and praised by customers!













Our Advantages
Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 5

1. Provide solutions to assist you in turning a product concept into reality.
2. Provide new product solutions to diversify your product lines.
3. Use our professions and experiences to help our clients cost down.
OEM Service





All of our products can be customized with any sizes, shapes, designs, LOGOs. We will be appreciated if you can provide the information below before we quote you the price:

1.Item Model No.

2.Material and thickness 3.Estimated quantity.
4.The printing area and color.
5.If it's custom shape items, please provide the 3D drawing.
6.Package that you need, you may check the reference as below picture:
Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 6





Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 7
PAYMENT TERM

* T/T or Bank Card 30% deposit before production, and 70% balance payment against the B/L draft.
* Made-ready Goods: T/T or Bank Card 100% payment before shipping out.

PACKAGING REMINDERS

* Normal Packing: We will put the goods into a brown inner box according our suitable packing rate first, then these inner boxes will put together into a brown outer carton.
* Packaging Customization: Available. It will occur extra custom packaging fee depend on client's required. (Such as Color inner box, Logo prinitng, single product individual packing...)



Electric Hood Type Dish Washer With Pre Cleaning And Exit Table 8




FAQ





Q1: Are you a factory?

A1: Yes. we have our own factory and we sale products by ourself, welcome you to visit our company and factory.

Q2: What payment method do you accept?

A2: We accept most of the payment methods, but mainly accept T/T,LC,Western Union, Alibaba assurance order.

Q3: Can you put my brand name (logo) on these products?

A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo for bulk orders.

Q4: May I know the status of my order?

A4: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.

Q5: What is shipping method?

A5: It depends on your requirement, all available, such as DHL/UPS/FedEX, TNT, special line, Air Cargo, Sea Cargo, Post, etc. We'll try our best to help you save money.

Q6: How to control the product quality in the process of production?

A6:We strictly follow the three-inspection quality inspection system, that is, self-inspection, mutual inspection and special inspection.Every link is strictly controlled to ensure the quality of products.

Q7: What about the quality?

A7: All the goods will past strict inspection before being sending out. And kindly please check the goods once you received and contact us in time. We will help you solve the problem if the goods have any damage.
